| ID | Category [?] | Severity [?] | Reproducibility | Date Submitted | Last Update |
|---|---|---|---|---|---|
| 06640 | Core | Major | Always | Aug 1, 2017, 21:38 | Aug 4, 2017, 06:43 |
| Tester | MrGW | View Status | Public | Platform | MAME (Official Binary) |
| Assigned To | Duke | Resolution | Fixed | OS | Windows 10 (32-bit) |
| Status [?] | Resolved | Driver | coco3.cpp | ||
| Version | 0.188 | Fixed in Version | 0.189 | Build | Normal |
| Summary | 06640: coco3, coco3h: TRS-80 Color Computer FDC data corruption issue | ||||
| Description | David Ladd (davidwladd@gmail.com) has discovered a serious data corruption issue when using the FDC with the COCOx drivers in MAME. He originally submitted MAME bug #6639 as part of an earlier issue he saw when running OS9 and accessing /d0 and /d1 drives (under certain circumstances). http://mametesters.org/view.php?id=6639 It looks like this latest discovery is what was causing the earlier issue. In any case, MAME 0.162 was the last version known to work correctly with the FDC. Something changed in MAME 0.163 to 'break' the FDC and it's been that way ever since. | ||||
| Steps To Reproduce | Here's a simple test that will demonstrate the issue: Startup CoCo 2 or CoCo3 emulation Create a new disk image in drive 0 Create a new disk image in drive 1 DSKINI 0 DSKINI 1 Enter a quick basic program like this and save it to disk: 10 PRINT 'DIR 0' 20 DIR 0 30 PRINT 'DIR 1' 40 DIR 1 50 GOTO 10 SAVE'TEST1.BAS' Then all you have to do to see the problem is to: DIR 0:DIR 1 You will see TEST1.BAS show up twice. Which it should not. The issue is also reproducible using the methods detailed in the videos below: | ||||
| Additional Information | Credit goes to David Ladd for finding this issue (twice). It was never resolved in the original MAME bug report: http://mametesters.org/view.php?id=6639 | ||||
| Flags | |||||
| Regression Version | |||||
| Affected Sets / Systems | coco3, coco3h | ||||
Attached Files | test_disks.zip (799 bytes) Aug 1, 2017, 23:53 Uploaded by Tafoid Test Disk Images - disk1 has program, disk2 is empty - both are formatted | ||||
coco.diff (683 bytes) Aug 2, 2017, 07:50 Uploaded by Osso [Show Content] | |||||
| ||||||
Bletch Aug 1, 2017, 22:11 | From the MAME 0.163 release notes: - update all drivers to use the new wd floppy controller implementation and remove the legacy one. I'm guessing that this is more than a coincidence. |
|---|---|
Tafoid Aug 1, 2017, 23:52 | Added disk1 and disk2 images to assist in testing. I've noticed that it doesn't always file the first time, but usually fails the 'DIR 0:DIR 1' test the 2nd time |
star2root Aug 2, 2017, 02:03 | I think it might have to with these changes… 85 src/emu/bus/coco/coco_fdc.c @@ -291,16 +298,17 @@ void coco_fdc_device::dskreg_w(UINT8 data) else if (data & 0x40) drive = 3; - legacy_floppy_image_device *floppy[4]; + floppy_image_device *floppy[4]; - floppy[0] = subdevice<legacy_floppy_image_device>(FLOPPY_0); - floppy[1] = subdevice<legacy_floppy_image_device>(FLOPPY_1); - floppy[2] = subdevice<legacy_floppy_image_device>(FLOPPY_2); - floppy[3] = subdevice<legacy_floppy_image_device>(FLOPPY_3); + floppy[0] = subdevice<floppy_connector>(WD_TAG ':0')->get_device(); + floppy[1] = subdevice<floppy_connector>(WD_TAG ':1')->get_device(); + floppy[2] = subdevice<floppy_connector>(WD_TAG ':2')->get_device(); + floppy[3] = subdevice<floppy_connector>(WD_TAG ':3')->get_device(); for (int i = 0; i < 4; i++) { - floppy[i]->floppy_mon_w(i drive ? CLEAR_LINE : ASSERT_LINE); + if (floppy[i]) + floppy[i]->mon_w(i drive ? CLEAR_LINE : ASSERT_LINE); } head = ((data & 0x40) && (drive != 3)) ? 1 : 0; @@ -309,8 +317,11 @@ void coco_fdc_device::dskreg_w(UINT8 data) update_lines(); - m_wd17xx->set_drive(drive); - m_wd17xx->set_side(head); + m_wd17xx->set_floppy(floppy[drive]); + + if (floppy[drive]) + floppy[drive]->ss_w(head); + m_wd17xx->dden_w(!BIT(m_dskreg, 5)); } @@ -379,7 +390,7 @@ WRITE8_MEMBER(coco_fdc_device::write) dskreg_w(data); break; case 8: - m_wd17xx->command_w(space, 0, data); + m_wd17xx->cmd_w(space, 0, data); break; case 9: m_wd17xx->track_w(space, 0, data); @@ -388,6 +399,7 @@ WRITE8_MEMBER(coco_fdc_device::write) m_wd17xx->sector_w(space, 0, data); break; case 11: + //printf('data w %02xn', data); m_wd17xx->data_w(space, 0, data); break; }; @@ -413,10 +425,12 @@ WRITE8_MEMBER(coco_fdc_device::write) //************************************************************************** static MACHINE_CONFIG_FRAGMENT(dragon_fdc) - MCFG_DEVICE_ADD(WD2797_TAG, WD2797, 0) - MCFG_WD17XX_DEFAULT_DRIVE4_TAGS + MCFG_WD2797_ADD(WD2797_TAG, XTAL_1MHz) - MCFG_LEGACY_FLOPPY_4_DRIVES_ADD(coco_floppy_interface) + MCFG_FLOPPY_DRIVE_ADD(WD2797_TAG ':0', coco_fdc_floppies, 'qd', coco_fdc_device::floppy_formats) + MCFG_FLOPPY_DRIVE_ADD(WD2797_TAG ':1', coco_fdc_floppies, 'qd', coco_fdc_device::floppy_formats) + MCFG_FLOPPY_DRIVE_ADD(WD2797_TAG ':2', coco_fdc_floppies, ', coco_fdc_device::floppy_formats) + MCFG_FLOPPY_DRIVE_ADD(WD2797_TAG ':3', coco_fdc_floppies, ', coco_fdc_device::floppy_formats) MACHINE_CONFIG_END @@ -511,10 +525,20 @@ void dragon_fdc_device::dskreg_w(UINT8 data) data); } - if (data & 0x04) - m_wd2797->set_drive(data & 0x03); + floppy_image_device *floppy = NULL; + + switch (data & 0x03) + { + case 0: floppy = subdevice<floppy_connector>(WD2797_TAG ':0')->get_device(); break; + case 1: floppy = subdevice<floppy_connector>(WD2797_TAG ':1')->get_device(); break; + case 2: floppy = subdevice<floppy_connector>(WD2797_TAG ':2')->get_device(); break; + case 3: floppy = subdevice<floppy_connector>(WD2797_TAG ':3')->get_device(); break; + } + + m_wd2797->set_floppy(floppy); m_wd2797->dden_w(BIT(data, 3)); + m_dskreg = data; } @@ -556,12 +580,7 @@ WRITE8_MEMBER(dragon_fdc_device::write) switch(offset & 0xEF) { case 0: - m_wd2797->command_w(space, 0, data); - - /* disk head is encoded in the command byte */ - /* Only for type 3 & 4 commands */ - if (data & 0x80) - m_wd2797->set_side((data & 0x02) ? 1 : 0); + m_wd2797->cmd_w(space, 0, data); break; case 1: m_wd2797->track_w(space, 0, data); |
Osso Aug 2, 2017, 07:52 | Attached a small patch which seems to work for this case, but may actually cause horrible breakage elsewhere since I know nothing about the coco hardware and haven't tested anything else. None the less, it might be useful as a hint of what's going wrong. |
Haze Aug 2, 2017, 13:33 | the original code is definitely suspicious, it looks like it will turn off the motor for every drive other than the one you're trying to access. so in that sense, I'd say your fix looks sane even if I know nothing about the system |
lostwizard Aug 2, 2017, 19:14 | In case it helps, the correct drive motor behaviour on the Coco FDC is: If the motor enable bit (bit 3 of FF40) is enabled, *all* drive motors should start and *stay* on until the motor enable bit is cleared. That is, the drive select lines have no effect on whether a drive is spinning or not. All are or none are. Edit: Also, if the drive motors are turned off (bit 3 of FF40 clear), the drive selects still operate and 'enable' the specified drive(s). The drive light actually comes on with the motors turned off on the real hardware in that case. However, I suspect another issue in addition to the drive motor behaviour since the drive not being spun up properly should result in a read failure (CRC fail leading to I/O error or obviously garbled data) rather than the described behaviour. |
No.14058 Tester | Osso, I just tested the patch you supplied. It doesn't fully address the issue. You can also do a DIR 1:DIR 0 and then the directory on drive 0 doesn't show up correctly. Also you can have up to 4 single side floppy drives or 3 double sided floppy drives connected to a real CoCo. |
No.14059 Tester | Ciaran Anscomb (from the Xroar project) provided this comment and patch to try: 'They've come up with a patch, but that fails in a different way. Suggest the attached: update motor state on *all* drives, not just selected.' diff --git a/src/devices/bus/coco/coco_fdc.cpp b/src/devices/bus/coco/coco_fdc.cpp index f56bc047c5..cf9bd3038c 100644 --- a/src/devices/bus/coco/coco_fdc.cpp +++ b/src/devices/bus/coco/coco_fdc.cpp @@ -277,7 +277,7 @@ void coco_fdc_device_base::dskreg_w(uint8_t data) { floppy_image_device *floppy = m_floppies[i]->get_device(); if (floppy) - floppy->mon_w(((i drive) && (data & 0x08)) ? CLEAR_LINE : ASSERT_LINE); + floppy->mon_w((data & 0x08) ? CLEAR_LINE : ASSERT_LINE); } head = ((data & 0x40) && (drive != 3)) ? 1 : 0; |
No.14060 Developer | Thanks lostwizard, just committed a patch according to your explanation. It seems to fully address the issue here. Would be good if someone could try 06639 now. |
No.14063 Tester | Just so everyone knows that Ciaran Anscomb patch seems to have fixed the Disk Basic & OS-9/NitrOS-9 problems I ran into and was doing random reading & writing to both drives for a few minutes and did not notice any corruptions at this time. Before if accessing both floppy drives at the same time would crash OS-9 before within a few seconds. The DIFF code Ciaran and supplied to us is as follows: diff --git a/src/devices/bus/coco/coco_fdc.cpp b/src/devices/bus/coco/coco_fdc.cpp index f56bc047c5..cf9bd3038c 100644 --- a/src/devices/bus/coco/coco_fdc.cpp +++ b/src/devices/bus/coco/coco_fdc.cpp @@ -277,7 +277,7 @@ void coco_fdc_device_base::dskreg_w(uint8_t data) { floppy_image_device *floppy = m_floppies[i]->get_device(); if (floppy) - floppy->mon_w(((i drive) && (data & 0x08)) ? CLEAR_LINE : ASSERT_LINE); + floppy->mon_w((data & 0x08) ? CLEAR_LINE : ASSERT_LINE); } head = ((data & 0x40) && (drive != 3)) ? 1 : 0; |
No.14064 Tester edited on: Aug 3, 2017, 02:16 | While we are in this file, I would like suggest a patch that addresses another minor issue. Currently the CoCo's available floppy setting are either none, or quad density. Most CoCo's had either SSDD or DSDD 5 1/4 drives. This patch below set the default number of drives to 3, and adds the ability to select SSDD, DSDD, or QD (quad density) drives as an option. It also includes the patch above to fix the data corruption issue. Ileft the default at QD since due to another existing bug I have not been able to fix yet, you can't change the drive setting until you select 'reset' from the slot devices menu and QD drives do work with almost all existing disk images. --- src/devices/bus/coco/coco_fdc.cpp 2017-08-02 01:36:40.000000000 -0400 +++ src/devices/bus/coco/coco_fdc.cpp 2017-08-02 22:13:09.000000000 -0400 @@ -118,6 +118,8 @@ FLOPPY_FORMATS_END static SLOT_INTERFACE_START( coco_fdc_floppies ) + SLOT_INTERFACE('ssdd', FLOPPY_525_SSDD) + SLOT_INTERFACE('dsdd', FLOPPY_525_DD) SLOT_INTERFACE('qd', FLOPPY_525_QD) SLOT_INTERFACE_END @@ -130,7 +132,7 @@ MCFG_FLOPPY_DRIVE_SOUND(true) MCFG_FLOPPY_DRIVE_ADD(WD_TAG ':1', coco_fdc_floppies, 'qd', coco_fdc_device_base::floppy_formats) MCFG_FLOPPY_DRIVE_SOUND(true) - MCFG_FLOPPY_DRIVE_ADD(WD_TAG ':2', coco_fdc_floppies, nullptr, coco_fdc_device_base::floppy_formats) + MCFG_FLOPPY_DRIVE_ADD(WD_TAG ':2', coco_fdc_floppies, 'qd', coco_fdc_device_base::floppy_formats) MCFG_FLOPPY_DRIVE_SOUND(true) MCFG_FLOPPY_DRIVE_ADD(WD_TAG ':3', coco_fdc_floppies, nullptr, coco_fdc_device_base::floppy_formats) MCFG_FLOPPY_DRIVE_SOUND(true) @@ -273,25 +275,32 @@ else if (data & 0x40) drive = 3; + // Enable/disable the motor line for all drives since it is common + // to all drives. for (int i = 0; i < 4; i++) { floppy_image_device *floppy = m_floppies[i]->get_device(); if (floppy) - floppy->mon_w(((i drive) && (data & 0x08)) ? CLEAR_LINE : ASSERT_LINE); + floppy->mon_w((data & 0x08) ? CLEAR_LINE : ASSERT_LINE); } + // Determine the value of the head (side) select line. head = ((data & 0x40) && (drive != 3)) ? 1 : 0; + // Update the floppy controller register set_dskreg(data); update_lines(); + // Select the floppy drive that is active. floppy_image_device *selected_floppy = m_floppies[drive]->get_device(); m_wd17xx->set_floppy(selected_floppy); + // Apply the side select value. if (selected_floppy) selected_floppy->ss_w(head); + // Set the density m_wd17xx->dden_w(!BIT(dskreg(), 5)); } |
drencorxeen Aug 4, 2017, 06:43 | Duke, So after hours of testing it does seem that the patch was made for coco_fdc.cpp has at least resolved this issue at this time. |
This rare poster depicts Rhodesia Regiment Troopies taking a quick tactical pause to discuss tactics so as to 'slot floppies' in the most efficient manner possible. Measures 12 inches x 18 inches, printed as a full bleed colour on extra thick 1.5mm glossy stock. Get the best deals on Floppy Disk Games and expand your gaming library with the largest online selection at eBay.com. Fast & Free shipping on many items! Leisure Suit Larry is an adult-themed video game series created by Al Lowe.It was published by Sierra from 1987 to 2009, then by Codemasters starting in 2009. The first six Leisure Suit Larry titles, along with Magna Cum Laude and Love for Sail Mobile, were distributed by Vivendi Games (now Activision Blizzard), while Box Office Bust and Reloaded were distributed by Codemasters. A derogatory term for an insurgent fighter who trended to be black. Originated with Rhodesian military personnel in Rhodesia (currently Zimbabwe) during the Rhodesian Bush War.
Chapter 11 - How to Install Games using the WHDLoad Installs
Back to Home Workbench 3.1 Guide Contents Site Map
In this chapter I will first show you how to add an HD-Games drive to your Workbench setup then give an example of how to install a WHDLoad game. (I will use Alfred Chicken as the example)
How to add an HD-Games drive:
a. In windows go into C:Program FilesWinUAEHard Disks then go to File > New > Folder and type in: HD-Games as the directory name.
b. Now launch the WinUAE program, left click the config you made, click the Load button.
c. Next go to the Hard Drives Properties and Left Click Add Directory...
d. In Volume Name: type in HD-Games
e. In Path type C:Program FilesWinUAEHard DisksHD-Games (or click ‘...’ button and point to this directory) and then click OK. See Chapter 1 for the screen captures
f. Now go back to the Configurations Properties
g. Left Click once on the config you made in Chapter 1 to select (i.e. Amiga 1200 WB3.1) and click the Save button.
How to install a WHDLoad game
1. Go to http://www.whdload.de/download.html and download the game patch Installs and save them to C:Program FilesWinUAEHard DisksPrograms
N.B. These installs mostly only work with Original Disks (or ipf images) and not pirate/cracked disks (or images). Also if you like WHDLoad and use it often, then it’s recommended you register to remove the 'nag' screen.
2. If you have quit WinUAE, then re-launch the program, left click the config you made, click the Load button and click OK/Start to start emulation.
3. When workbench is booted you should see Ram Disk, HD-Games, Programs and System. Double click System, double click the next System drawer in the window that opened, and then double click the Shell program to open Amiga DOS.
4. Type in:
lha x Programs:AlfredChicken.lha Programs: and press Return/Enter
5. Now close shell (type endcli and press Return/Enter) then Double Click Programs and on AlfredChickenHD drawer directory.
6. Now double click on Install
7. Make sure Intermediate User is selected and then Click ‘Proceed With Install.’ (in this install you can see the Novice User is greyed out and unavailable, this is normal, so don’t worry)
8. Make sure Install for Real and None are selected and then Click ‘Proceed’. (You can see the Pretend to Install is also greyed out and unavailable, again this is normal, so don’t worry)
9. The ReadMe will now open, so click top-left square to close it.
10. Left click on DH2: HD-Games:
11. Click 'Proceed'
Slot Floppies Patch
12. Select the type of icon to use (select Exotic or Non-Exotic NewIcon if you have Scalos or NewIcons installed, select Normal if you have Magic Workbench or have No Workbench enhancements installed). Once you have made your selection, click ‘Proceed’
13. When this screen shows press F12 on you keyboard. (On a real Amiga just insert Alfred Chicken floppy disk into you internal disk drive and ignore step 14)
14. Now on the floppies Properties select the '...' button on the DF0: slot and select your Alfred Chicken adf. Click Open and then the OK button to return back to emulation.
15. Now wait 5 seconds, if the copying of files does not begin automatically then click ‘Proceed’ when Alfred Chicken disk icon shows on the Workbench desktop screen.
16. When this window shows, click 'Proceed' to end the Install.
17. Now close all open windows and remove the Floppy disk in your real Amiga or Press F12 and click eject on the floppies Properties to eject the adf image.
18. Double Click HD-Games
19. Double Click the AlfredChicken drawer
20. Double Click AlfredChicken Icon to run the game.
